HYP40
4 TON DIESEL FORKLIFT
| Rated load | 4000KG |
| Load center distance | 500mm |
| Free lifting height | 160mm |
Price: $31,900.00 Incl. GST
Dealer Costs not Included and May Vary.
Product Parameters
| Rated load | 4000KG |
| Load center distance | 500mm |
| Free lifting height | 160mm |
| Full length (fork/without fork) | 4000/2930mm |
| Full width | 1290mm |
| Full height (overhead guard) | 2180mm |
| Wheelbase | 1900mm |
| Minimum ground clearance (at the door frame) | 140mm |
| Mast Tilt Angle(Front/Rear) | 6°/12° |
| Tire No. (Before) | 250-15-16PR |
| Tire No. (After) | 7-12-12PR |
| Minimum turning radius (outer sid) | 2710mm |
| Minimum right angle channel width | 4750mm |
| Fork size L*W*T | 1070*150*50 mm |
| Maximum travel speed (laden/unladen) | 19/19km/h |
| Maximum lifting speed (full load/no load) | 340/380mm/s |
| Maximum gradeability machinery (full load/no load) | 15/20% |
| Gross weight | 4950KG |
| Engine Brand | XINCHAI |
| Engine Model | 495 |
| Fuel | diesel engine |
| Power | 48/2500KW/rpm |
| Torque | 187/1800Nm/rpm |
