XHD20
2 TON ELECTRIC FORKLIFT
Electric Forklift Advantages:
Small excavators are very suitable for farm orchard and small construction site and rural families. Application scenarios include farm trenching, aqua toilet renovation, vegetable greenhouse trenching, green belt repair, etc.
Everything in the Standard Machine & Implements Package:
| Loading Capacity | 2 Ton |
| Battery Type | Lead-Acid Battery |
| Lift Height | 3000mm |
-
Easy to Operate in a Small Space
- Rubber Tyres
- Less Noisy
- Zero Emissions
- 1 Year / 1000 Hours Warranty
- Australian-Backed Parts Support
- Extended Warranty Options Available for 2 /3 Years
Price: $16,990.00 Incl. GST
Dealer Costs not Included and May Vary.
Product Parameters
| Loading Capacity | 2 Ton |
| Battery Type | Lead-Acid Battery |
| Lift Height | 3000mm |
| Model | XHD20 |
| Driving Mode | Seated |
| Rated Capacity | 2000Kg |
| Load Center Distance | 500mm |
| Power Mode | Lead-Acid Battery |
| Wheel Base | 1550mm |
| Travel Speed, Laden/Unladen | 8/9.5km/h |
| Lifting Speed, Laden/Unladen | 180/200mm/s |
| Lowering Speed, Laden/Unladen | 550mm/s |
| Maximum Negoniable Gradient,Laden/Unladen | 15/20% |
| Service Mass (with battery) | 2500kg |
| Axle Load:Unloaded, Front/Rear | |
| Axle Load:Loaded, Front/Rear | |
| Battery Voltage / Nominal Capacity | 60V/210Ah V/Ah |
| Battery Weight | 300kg |
| Drive Motor Power-60 Minutes | |
| Lift Motor Power-15 Minutes | 4.5 Permanent Magnet Synchronization kw |
| Drive Motor Controlling Mode | MOSFET/PMSM |
| Lifting Motor Controlling Mode | MOSFET/PMSM |
| Service Brake/Parking Brake | Hydraul ic/Mechanial |
| Tyre Type | Solid Tire |
| Wheels Number (front/rear) | 2/2 |
| Front Track | 945mm |
| Rear Track | 880mm |
| Tyre (front) | 18*7 -10 |
| Tyre (rear) | 15*4 1/2-8 |
| Front Overhang | 325mm |
| Tilt Of The Mast,Front/Rear | 5/10 |
| Height Mast Retraction | 2030mm |
| Free Lift Height | |
| Overall Maximum Lift Height | 3000mm |
| Height,mast extended | 4055mm |
| Overhead Guard Height | 2110mm |
| Lateral Fork Adjustment (Outside Of Forks)Max/Min | 1040/100mm |
| Fork Size(L*W*T) | 45*100*1070mm |
| Truck Body Length(Fork Excluded) | 2230mm |
| Truck Body Width | 1096mm |
| Turning Radius | 2200mm |
| Groubd Clearance Under Mast | 88mm |
| Ground Clearance At Center Of Wheelbase(Laden) | 110mm |
| Width Of Aisle Right-Angle Stacking (pallet 1000x1000mm clearance 200mm) | 3750mm |
| Width Of Aisle Right-Angle Stacking (pallet 1200x1200mm clearance 200mm) | 3950 |
